Application Instructions
STEP 1: PREPPING THE SURFACE
- Thoroughly clean vehicle using FEYNLAB® PURE WASH.
- Follow with a topical decontamination clay treatment using FEYNLAB® PRIME. If necessary, use a ferrous iron removal product to remove all embedded iron deposits.
- After polishing paint to the desired level, remove all polish oils using FEYNLAB® PANEL PREP to ensure optimal bonding and durability of the coating.
- Prior to application, place the vehicle in a well-lit, temperature controlled (10°C 30°C/50°F-85°F), and contaminated free environment. Have plenty (6 or more) new microfiber towels, 3-2 microfiber sponge applicators, or 2-1 foam applicators on hand BEFORE application.
- Once the car is prepared, we recommend taping off and protecting all unapproved surfaces. By performing this step, you minimize the risk of etching by the solvents in OVERCOAT V3 on unapproved surfaces* such as rubber lining around windows and doors.
- *Avoid these surfaces with OVERCOAT V3 and wipe off immediately if any contact occurs.
- Shake the product vigorously for 30 seconds before use.
- If applying over another FEYNLAB® coating, wait 2 hours (minimum of 1.5 and a maximum of 3 hours) for the base coating to set up. Then apply in the same application pattern as the base coating.
STEP 2: APPLYING THE PRODUCT
- Apply enough OVERCOAT V3 to a microfiber applicator to fully cover 2 panels.
- Make a “+” (plus) sign with the product in the middle of the panel, then wipe around the boundaries of the section creating a frame.
- Next, fill in the framed area with slightly overlapping horizontal (left to right) straight lines over the entire panel. After, switch to vertical overlapping lines. This cross-hatching pattern ensures even application.
- Immediately wipe the 2 panels that have OVERCOAT V3 on them, following the same pattern of application, using two clean microfiber towels.
– Towel A (left hand) will remove (level) the majority of coating residue.
– Towel B (right hand) will remove any remaining residue, revealing a crystal clear surface. - If the surface is difficult to wipe clear (hazy) reduce the application area.
- Recommended Maximum Area of Application: 2 panels ONLY, then wiping off in the same pattern as the application.
STEP 3: FINAL INSPECTION
- Carefully inspect all finished panels for any leftover coating residue (high spots) during the final wipe. Commonly edges, emblems, and other tight areas may contain some remaining residue. High spots are much easier to remove if caught within a 40-20 min window after the final wipe than later, when the coating has set-up and curing has started.
- Avoid any incidental water exposure for 24 hours. If it occurs, gently wipe water off the surface.
– Avoid all chemicals, including car washes for 7 days.
– Wash & Maintain using FEYNLAB® PURE WASH or FEYNLAB® PURE RINSELESS.
INFRARED CURING
OVERCOAT V3 Alone
Bake each panel with an IR lamp to reach a surface temperature of 60°C (140°F) for 15 min at a distance of ~36-30″ from the panel.
OVERCOAT V3 OVER ANOTHER COATING
- If applying over another coating, install base coating layer first per instructions for that coating.
- Wait 2 hours*, then install OVERCOAT V3 in the same application pattern as the base coating.
- After OVERCOAT V3 is applied to all surfaces, immediately bake each panel with an IR lamp to reach a surface temperature of 60°C (140°F) for 15min at a distance of ~ 36-30″ from the panel.
- *In order to form a covalent bond, Overcoat V3 should be applied within 1.5 to 8 hours of base coating.
